2023 NS38 Rim Brake (NEW)

Regular price

THE LIGHT, THE NIMBLE

The discerning choice -our lightest wheel provides for the greatest possible acceleration and best handling, delivering a very snappy take off feeling. The minimal depth profile keeps weight down and provides the most stability against cross winds.

Great in climbing scenarios and for the long distance riders. The shallower profile also reduces stiffness -more flexible, improving handling on rough roads and maneuvering, a must in technical ascents and descents. This sizing is often chosen by many riders in long and technical courses such as at Tour de France.

Every component in the NS-Road line design has been carefully evaluated on its ability to absorb impact and vibration, minimise overall weight and deliver great gains in aero efficiency. As a result, responsive-stiff-lightweight wheels are now accessible to all of us. We challenged status quo and did the unthinkable: increasing both performance and affordability.

WHY?

// Excellent cross wind performance
// Aerodynamic boost, free speed for the du/triathletes and road racers
// Reduced vibration, increased impact absorption, more stable, better control
// Lightweight, same effort takes you further
// Faster acceleration and ability to hold top speed longer.



    THESE WHEELS

    CERTIFICATION

    UCI APPROVED [RIM BRAKE & DISC BRAKE]

    FERNMARK LICENCE NO. 100715

    WEIGHT Front 685g Rear 885g Rim Brake / Front 760g Rear 870g Disc Brake | Wheels only / no cassette, tyres, tubes or rotors
    TYRE SYSTEM Tyres and tubes, or tyres only (tubeless)
    TYRE COMPATIBILITY Recommended tyre widths: 23mm - 28mm

    OVERALL DIMENSION

    700C ⌀632mm
    WIDTH 19mm internal / 25mm external rim width
    DEPTH 38mm rim depth
    RIM Carbon Fibre Toray T700, U-shape
    HUBS

    DT Swiss 350 Straightpull Centerlock for Disc Brake [12x100mm / 12x142mm Through Axle (standard)] 136g Front + 268g Rear

    DT Swiss 350 Classic for Rim Brake [9x100mm / 10x130mm Quick Release (standard)] 148g Front + 265g Rear

    Ratchet system 18 and Steel bearings

    See compatibility guide

    SPOKES

    Count | Front 20 Rear 24 Rim Brake | Front 24 Rear 24 Disc Brake

    Pattern | Front Radial | Rear Two-cross/Radial (2:1)

    Material | Stainless steel Sandvik T302+

    Sapim CX-Leader (6.7g/pc)

    Straightpull for Disc Brake / J-bend for Rim Brake

    NIPPLES Visible
    TAPE Yes - Rim bead protection (no Tubeless tape installed)
    FINISH UD - Black matte | Coated decals (NOT STICKERS / NOT REMOVABLE)  | Outline Black
    BRAKING SYSTEM

    Disc brake | Centrelock

    Rim Brake | V-Brake

    Valve extenders recommended if using a 50mm Presta valve (tube) - How to install valve extenders

    Rim brake surface: Carbon, basalt and resin TG (190-200C) (12mm)

    ASSEMBLY Proudly hand-built by the world's greatest carbon fibre artisans in Xiamen, People's Republic of China
    MAXIMUMS

    Generally 85-100psi (Max 110 / Min 80) -check your tyre manufacturer max and low pressures

    Max rider weight 130kg

    PACKAGE

    Moved using local couriers - air and land transportation as required

    800mm x 650mm x 170mm, 3.6kg

    Included in the box:

    -Wheelset & Cassette spacer for 8/9/10 speed Shimano/SRAM

    -Rim tape installed

    -Booklet -Welcome to nscarbon, Set up and Maintenance guide

    -Quick release | Aluminium alloy 48g Front 53g Rear (Rim Brake only)
